Phaser 3010/3040/WorkCentre 3045 Service Xerox Internal Use Only 2-75
Error Troubleshooting
Paper Size Mismatch
The size of paper in the Main Paper Tray, or Bypass Tray, does not match the
specified print size.
Applicable Error
• 024-958: Paper Size Match
Initial Actions
• Check that the correct paper is in the paper tray. Change the paper if
necessary.
• Cycle printer power.
• If the problem persists, use the following procedure.
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ Registration Sensor, PL2.3.10
■ Regi Sensor Harness, PL2.3.22
■ MCU Board, PL7.1.3
■ “Map 1” on page 7-3
■ “Drive” on page 7-14
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 Check connectors P/J23 and P/J230
between the MCU Board and the
Registration Sensor.
Are the connections secure?
Go to Step 2. Secure the
connectors.
2 Does the error persist? Go to Step 3. Complete.
3 Disconnect P/J23 and P/J230. Check
harness continuity.
Is the harness damaged?
Repair the
harness.
Go to Step 4.
4 Disconnect the MCU Board P/J23.
Is the voltage across ground and
J23-1 +3.3 VDC?
Replace the
Registration
Sensor
(page 4-30).
Replace the
MCU Board
(page 4-43).
