![Xerox Phaser 3010 [63/430] Printing the error history report at the phaser 3045 control panel](/img/pdf.png)
Xerox Phaser 3010 [63/430] Printing the error history report at the phaser 3045 control panel
![Xerox Phaser 3010 [63/430] Printing the error history report at the phaser 3045 control panel](/views2/1228085/page63/bg3f.png)
Phaser 3010/3040/WorkCentre 3045 Service Xerox Internal Use Only 2-9
Error Troubleshooting
Error History Report
The Error History Report provides a list of error messages and codes relating to
jams and system errors.
The Error History page contains two types of history information.
• System Fail History contains: Date, Time, Chain-Link code, and Error
Information.
• Paper Jam History contains: Date, Time, Chain-Link code and Paper Jam Type.
Printing the Error History Report with the Printer Settings Utility
1. From the Start Menu, select Programs > Xerox Office Printing >Phaser
3010/3040 > Printer Settings Utility.
2. On the Printer Settings Report tab, select Information Pages.
3. Press the Error History button.
The Error History Report is printed.
Note
If the Error History Report will not print due to printer failure, see “Phaser
3010/3040 Error Codes” on page 2-10.
Printing the Error History Report at the Phaser 3045 Control Panel
1. At the Control Panel, press the System button.
2. Select Information Pages, press OK.
3. Press the Up or Down arrow button to find Error History. Press OK.
