Xerox Phaser 3010 [157/430] Exit jam
![Xerox Phaser 3010 [157/430] Exit jam](/views2/1228085/page157/bg9d.png)
Phaser 3010/3040/WorkCentre 3045 Service Xerox Internal Use Only 2-103
Error Troubleshooting
Exit Jam
Paper remaining at the Exit section of the Printer was detected.
Warning
Allow the Fuser to cool before servicing the printer.
Applicable Error
• 077-900: Exit Jam
Initial Actions
• Check the media path for obstructions or debris.
• Cycle printer power.
• If the problem persists, use the following procedure.
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ Fuser, PL5.1.1
■ MCU Board, PL7.1.3
■ “Map 2” on page 7-4
■ “Fuser” on page 7-18
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 Check P/J18 on the MCU Board.
Is P/J18 connected securely.
Go to Step 2. Secure P/J18.
2 Replace the Fuser (page 4-38).
Does the error persist?
Replace the
MCU Board
(page 4-43).
Complete.
