2-102 Xerox Internal Use Only Phaser 3010/3040/WorkCentre 3045 Service
Error Troubleshooting
Rear Door Open
A Rear Cover Open error was detected.
Applicable Error
• 077-304: Rear Cover Open
Initial Actions
• Open and close the Rear Door.
• Cycle printer power.
• If the problem persists, use the following procedure.
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ Rear Door, PL1.0.8
■ Interlock Switch, PL7.2.1
■ LVPS, PL7.2.11
■ MCU Board, PL7.1.3
■ “Map 2” on page 7-4
■ “LVPS” on page 7-13
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 Visually inspect the Rear Door for
actuator damage.
Is the Rear Door damaged?
Replace the
Rear Door
(page 4-8).
Go Step 2.
2 Test the Rear Door Interlock Switch.
Does the switch function correctly?
Go to Step 3. Replace the
switch
(page 4-44).
3 Replace the LVPS (page 4-48).
Does the error persist?
Replace the
MCU Board
(page 4-43).
Complete.
