Phaser 3010/3040/WorkCentre 3045 Service Xerox Internal Use Only 2-51
Error Troubleshooting
WorkCentre 3045 4-in-1 Parameters
Usse the parameter menu to set values for the parameters listed in the table
below.
Parameter Menu Value Options
Pulse Dialing
Enable Pulse Dialing
a
0:Disable, 1: Enable
Pulse dial make/break ratio 0: 30% / 70%, 1: 32% / 68%
2: 33% / 67%, 3: 36% / 64%
4: 38% / 62%, 5: 39% / 61%,
6: 40% / 60%, 7: 42% / 58%
Enable 20 PPS DP
b
0:Disable,1:Enable
DTMF Tone DTMF high tone level (-dB) 0: -3 dB, 1: -4 dB, 2: -5 dB,
3: -6 dB, 4: -7 dB, 5: -8 dB,
6: -9 dB, 7: -10 dB
DTMF high/low level
difference (dB)
0: 0 dB, 1: -1 dB, 2: -2 dB,
3: -3 dB, 4: -4 dB, 5: -5 dB
DTMF Dialing Speed (ms) 0: 70 ms, 1: 80 ms, 2: 85 ms,
3: 90 ms, 4: 95 ms, 5: 100 ms,
6: 105 ms, 7: 110 ms
Ring
Detection
Freq Range @ On Period --
Upper Bound
27~85Hz
Freq Range @ On Period --
Lower Bound
13~20 Hz
Minimum On time 0: 100ms, 1: 110ms, 2: 120ms,
3: 130ms, 4: 140ms, 5: 150ms,
6: 160ms, 7: 170ms, 8: 180ms,
9: 190ms, 10: 200ms, 11: 210ms,
12: 220ms, 13: 230ms,
14: 240ms, 15: 250ms
Off time 0: 500ms, 1: 600ms, 2: 700ms,
3: 800ms, 4: 900ms, 5: 1000ms,
6: 1100ms, 7: 1200ms,
8: 1300ms, 9: 1400ms,
10: 1500ms, 11: 1600ms,
12: 1700ms, 13: 1800ms,
14: 1900ms, 15: 2000ms
