Xerox Phaser 3010 [119/430] Email errors
![Xerox Phaser 3010 [119/430] Email errors](/views2/1228085/page119/bg77.png)
Phaser 3010/3040/WorkCentre 3045 Service Xerox Internal Use Only 2-65
Error Troubleshooting
Email Errors
An email error is detected.
Applicable Error
• 016-720: PDL Error
• 016-764: Connect Error
• 016-766: SMTP Error
• 016-767: Email Address Error
Initial Actions
• Cycle printer power.
• If the problem persists, use the following procedure.
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ IP Board, PL7.3.3
■ MCU Board, PL7.1.3
■ “Map 3 - IP Board” on page 7-8
■ “IP Board” on page 7-19
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 Reseat all connectors on the IP
Board and the MCU Board.
Does the error persist?
Go to Step 2. Complete.
2 Replace the IP Board (page 4-45).
Does the error persist?
Go to Step 3. Complete.
3 Replace the MCU Board (page 4-43).
Does the error persist?
Contact your
designated
field support for
assistance.
Complete.
