Phaser 3010/3040/WorkCentre 3045 Service Xerox Internal Use Only 2-29
Error Troubleshooting
FAX/Scanner Diagnostic Tests
Skew ■ -630 to 630 Adjusts the skew so that the image is
parallel with both sides of the paper.
Life
Counter Name Value
These counter values
are reference only. Do
not use as the official
value.
M/C Total PV 30000
M/C FC PV -
DEVE
Roundtime
-
XERO
Roundtime
-
M/C DispTime -
LM/C Pixel -
M/C
ColorEmptyBW
-
M/C Custom
Start
-
M/C Custom End -
Waste Toner -
Toner PV Std.: 700/High:14000
Toner DispTime -
Toner TDCC -
Toner Pixel -
Print Selecting this menu item prints the parameter values and life
counter values stored in the IOT.
Tes t Control Panel Description
Information Tests FAX and Scanner components.
Scan Counter FB: 0x00000000
ADF: 0x00000000
Displays the scan counter value.
■ FB: Platen scans
■ ADF: ADF scans
Scanner Maintenance
White Balance White Balance Reports the result of white balance
which is performed while the printer
powers up.
Registration
Param.
This function adjusts the registration
parameters of the scanner.
Parameter Range Description
Regi ADF Lead -2.0 mm ~ 2.0 mm,
in 0.1 mm Steps
Adjusts Registration of the ADF
leading edge.
Regi ADF Side -1.0 mm ~ 1.0 mm,
in 0.1 mm Steps
Adjusts Registration of the ADF side
edge.
Tes t Control Panel Test Description
