2-64 Xerox Internal Use Only Phaser 3010/3040/WorkCentre 3045 Service
Error Troubleshooting
PDL/PJL Error
There is something in the job that cannot be resolved by the driver.
Applicable Error
• 016-720: PDL Request
• 016-749: PJL request
Initial Actions
• Cycle printer power.
• Install the latest print driver.
• If the problem persists, use the following procedure.
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ IP Board, PL7.3.3
■ MCU Board, PL7.1.3
■ “Map 3 - IP Board” on page 7-8
■ “IP Board” on page 7-27
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 Check the print driver version.
Is the driver current and correct?
Go to Step 2. Install the
latest print
driver.
2 Replace the IP Board (page 4-45).
Does the error persist?
Go to Step 4. Complete.
3 Replace the MCU Board (page 4-43).
Does the error persist?
Contact your
designated
field support for
assistance.
Complete.
