2-76 Xerox Internal Use Only Phaser 3010/3040/WorkCentre 3045 Service
Error Troubleshooting
No Suitable Paper
The Main Paper Tray, or Bypass Tray, has run out of paper, or the size (or type) of
paper does not match the specified print size (or type).
Applicable Error
• 024-963: No Suitable Paper
Initial Actions
• Check that the correct paper is in the paper tray. Change, or load, the paper if
necessary.
• Cycle printer power.
• If the problem persists, use the following procedure.
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ Registration Sensor, PL2.3.10
■ Regi Sensor Harness, PL2.3.22
■ MCU Board, PL7.1.3
■ “Map 1” on page 7-3
■ “Drive” on page 7-14
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 Check connectors P/J23 and P/J230
between the MCU Board and the
Registration Sensor.
Are the connections secure?
Go to Step 2. Secure the
connectors.
2 Does the error persist? Go to Step 3. Complete.
3 Disconnect P/J23 and P/J230. Check
harness continuity.
Is the harness damaged?
Repair the
harness.
Go to Step 4.
4 Replace the IP Board (page 4-45).
Does the error persist?
Go to Step 5. Complete.
5 Disconnect the MCU Board P/J23.
Is the voltage across ground and
J23-1 +3.3 VDC?
Replace the
Registration
Sensor
(page 4-30).
Replace the
MCU Board
(page 4-43).
