Phaser 3010/3040/WorkCentre 3045 Service Xerox Internal Use Only 1-19
General Information
Specifications
Printing Specifications
Characteristic Specification
Printing Technology Recording System: LED electro-photographic system
using OPC Drum and direct transfer to the media.
Exposure System: LED printhead
Transfer System: Finished image is transferred onto the
media
Fusing System: Thermal fusing system by belt
Print Volume Average 250 PV/month
Maximum 20,000 PV/month
Median 300 PV/month
Color Medium Black Toner Cartridge
Resolution /
Addressability (dpi)
Standard 600 x 600
Enhanced 1200 x 1200
Print-Quality Mode 600 x 600 (Standard)
1200 x 1200 (Enhanced)
Average Image
Coverage
Mono 5%
Maximum Image
Coverage
240%
Printer Life 30,000 pages or 5 years
Maximum Duty
Cycle
20,000 KPV/month*
Warm-Up Time Less than 25 seconds from Power On
Operating System Windows 2003/2008 Server/ XP/ Vista/
Windows7
Macintosh OS 10.5 and greater
Linux Redhat and SuSe
* Assumes a 30 day month of printing.
