Xerox Phaser 3010 [173/430] Power supply troubleshooting
![Xerox Phaser 3010 [173/430] Power supply troubleshooting](/views2/1228085/page173/bgad.png)
Phaser 3010/3040/WorkCentre 3045 Service Xerox Internal Use Only 2-119
Error Troubleshooting
Power Supply Troubleshooting
AC Power Troubleshooting
Initial Actions
• Cycle printer power.
• If the problem persists, follow the procedure below.
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 When the printer is turned on, can
you hear the motor?
Go to “DC Power
Troubleshooting”
on page 2-120.
Go to step 2.
2 Connect the power cord to a
different outlet.
Does the printer now work?
Complete. Go to step 3.
3 Check that the power cord is
plugged in to both the printer and
the outlet.
Does the printer now work?
Complete. Go to step 4.
4 Disconnect the power cord and wait
1 minute. Reseat all of the
connectors on the LVPS, and then
turn the printer on.
Does the printer now work?
Complete. Go to step 5.
5 Disconnect the power cord and wait
1 minute. Reseat the AC Inlet
Harness, and then turn the printer
on.
Does the printer now work?
Complete. Replace the
LVPS
(page 4-48).
