2-66 Xerox Internal Use Only Phaser 3010/3040/WorkCentre 3045 Service
Error Troubleshooting
USB Memory Removal Error
USB memory is removed while memory reading job is being executed.
Applicable Error
• 016-791: USB Memory Removal Error
• 016-795: File Format Error
• 016-797: File Read Error
Initial Actions
• Cycle printer power.
• If the problem persists, use the following procedure.
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ Front USB Board, PL1.1.29
■ IP Board, PL7.3.3
■ MCU Board, PL7.1.3
■ “Map 3 - IP Board” on page 7-8
■ “IP Board” on page 7-27
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 Reseat the Front USB Board
connection.
Does the error persist?
Go to Step 2. Complete.
2 Replace the Front USB Board
(page 4-65).
Does the error persist?
Go to Step 3. Complete.
3 Replace the IP Board (page 4-45).
Does the error persist?
Go to Step 4. Complete.
4 Replace the MCU Board (page 4-43).
Does the error persist?
Contact your
designated
field support for
assistance.
Complete.
