Phaser 3010/3040/WorkCentre 3045 Service Xerox Internal Use Only 2-27
Error Troubleshooting
Scanner Test 2 ■ ADF Motor -On
■ ADF Motor -Off
This test checks the motor system for
the ADF document handling.
All Test
■ Start
■ Processing
■ Check OK or
<Failed Test> Error
This test runs all ESS Diag tests except
OP Panel, USB Host test, Lamp test, and
the Scanner test. Test returns Check OK
or failed test name.
IOT Diag Tests for print engine components.
Sensor Test At the start,
L - 0 is displayed.
When a sensor is
turned On from Off, L
changes to H and
back to L while the
counter increments.
Component Tests
These tests check whether the sensors
operate normally. Press OK to run the
selected test. Press Stop to exit the test.
The display returns to the Service Mode
menu.
NOTE During the Sensor Test, no other
diagnostic functions can be performed.
The printer only accepts DI components
and exit commands.
Tes t Co mpo ne nt
Exit Sensor Exit Sensor
Regi Sensor Registration Sensor
Interlock Switch Interlock Switch
K CRU Toner Cartridge CRUM
Motor Test These tests check operation of the electromechanical
components. Press OK to run the selected test. Press Stop to
exit the test. The display returns to the Service Mode menu.
NOTE During the Motor Tests, no other diagnostic functions can be performed.
The printer only accepts component and exit commands.
Component Tests
Tes t Co mpo ne nt
Main Motor (FULL)
Main Motor (SLOW)
Main Drive Motor
Caution: When checking the Main
Motor, stop the test within 10
seconds. Executing this test
for 10 seconds or longer may
damage the printer.
Feed Solenoid Feed Solenoid
Toner Motor Toner Motor
Caution: When checking the toner
motors, stop the test within 3
seconds. Executing this test
for 3 seconds or longer may
cause damage to the printer.
DBAC ON
NOTE The use of DBAC ON, DBDC ON, TR1+ ON,
TR2+ ON, TR2- ON, CR ON, MOB LED ON,
ADC LED ON, 24V ON, HV CLK ON is
prohibited to avoid shock hazards since
they are high-voltage outputs.
DBDC ON
TR1+ ON
TR2+ ON
TR2- ON
CR ON
MOB LED ON
ADC LED ON
24V ON
HV CLK ON
NVM Settings Edits, saves, loads, and prints NVM information.
Tes t Control Panel Test Description
