Phaser 3010/3040/WorkCentre 3045 Service Xerox Internal Use Only 2-105
Error Troubleshooting
XERO Near Life
The xerographics assembly is approaching end of life.
Applicable Error
• 091-402: XERO Near Life
Initial Actions
• Cycle printer power.
• If the problem persists, use the following procedure.
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ MCU Board, PL7.1.3 ■ “Xerographics” on page 7-15
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 Turn the printer off and then on.
Does the error persist?
Replace the
MCU Board
(page 4-43).
Complete.
2 Does the error persist? Contact your
designated
field support for
assistance.
Complete.
