2-118 Xerox Internal Use Only Phaser 3010/3040/WorkCentre 3045 Service
Error Troubleshooting
Abnormal Noises
Electrical Noise
Initial Actions
• Cycle printer power.
• If the problem persists, follow the procedure below.
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 Are there any other electrical
appliances within 3 meters of the
printer, such as generators, radio
and appliances with motors?
Either turn off the other electrical
appliances, or relocate the printer at
least 6 meters from other
appliances.
Does the electrical noise error still
occur?
Go to step 2. Complete.
2 Is AC power supply outlet wired and
grounded appropriately?
Go to step 3. Relocate the
printer.
3 Reseat the Toner Cartridge.
Does the electrical noise error still
occur?
Go to step 4. Complete.
4 Check system ground points.
Are the contacts clean and
undamaged?
Reseat the
connectors on
the HVPS.
Clean or repair
ground
contacts.
