2-114 Xerox Internal Use Only Phaser 3010/3040/WorkCentre 3045 Service
Error Troubleshooting
System Restart
An internal IP Board error occurred.
Applicable Errors
Initial Actions
• Cycle printer power.
• If the problem persists, use the following procedure.
117-331: System Restart 117-344: System Restart
117-332: System Restart 117-346: System Restart
117-333: System Restart 117-348: System Restart
117-334: System Restart 117-349: System Restart
117-340: System Restart 117-350: System Restart
117-342: System Restart 117-351: System Restart
117-343: System Restart 117-366: System Restart
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ IP Board, PL7.2.8 (3010/3040)
■ IP Board, PL7.3.3 (3045)
■ “IP Board” on page 7-19
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 Check the connectors on the IP
Board.
Are the connections secure?
Go to Step 2. Securely
reconnect the
connectors,
then go to
Step 2.
2 Does the error persist? Go to Step 3. Complete.
3 Replace the IP Board (page 4-45).
Does the error persist?
Complete.
