Phaser 3010/3040/WorkCentre 3045 Service Xerox Internal Use Only 1-29
General Information
Media and Tray Specifications
Media recommended for use with this printer is known as standard paper. The feed
performance, reliability, and print quality satisfy the specifications.
The following table lists supported media for the Phaser 3010/3040/WorkCentre
3045 printers.
The following table lists supported media types for the Phaser 3010/3040 printers.
Supported Media Sizes
Size MainTray Bypass Tray
A4 (210 x 297 mm (8.27 x 11.69 in.)) Y Y
B5 (182 x 257 mm (7.17 x 10.12 in.)) Y Y
A5 (148 x 210 mm (5.83 x 8.27 in.)) Y Y
C5 (162 x 229 mm (6.38 x 9.02 in.)) Y Y
Monarch (98 x 191 mm (3.875 x 7.5 in.)) Y Y
Monarch LEF (191 x 98 mm (7.5 x 3.875 in.)) Y Y
Envelope #10 (105 x 241 mm (4.125 x 9.5 in.)) Y Y
DL (110 x 220 mm (4.33 x 8.66 in.)) Y Y
DL LEF (220 x 110 mm (8.66 x 4.33 in.)) Y Y
Letter (216 x 279 mm (8.5 x 11 in.)) Y Y
Legal (216 x 356 mm (8.5 x 14 in.)) Y Y
Folio (216 x 330 mm (8.5 x 13 in.)) Y Y
Executive (184 x 267 mm (7.25 x 10.5 in.)) Y Y
Custom Y Y
Width: 76.2 to 215.9 mm (3 to 8.5 in.)
Length: 127 to 355.6 mm (5 to 14 in.)
Maximum width of 220 mm for envelope (DL LEF)
Minimum length of 98.4 mm for envelope (Monarch LEF)
Phaser 3010/3040 Supported Media Types
Media
Weight (g/
m
2
) Main Tray
Bypass Tray
Plain 60 to 90 Y Y
Plain Thick 91 to 105 Y Y
Recycled 60 to 105 Y Y
Label
a
-YY
Covers Normal (lightweight card stock) 106 to 163 Y Y
Coated Normal
a
(lightweight glossary
card stock)
a. Inkjet printer paper cannot be used.
106 to 163 Y Y
Envelope - Y Y
Postcard
