2-90 Xerox Internal Use Only Phaser 3010/3040/WorkCentre 3045 Service
Error Troubleshooting
Fax Transmit Error
Applicable Error
• 034-712: Communication Error (TX communication error is detected)
• 034-713: Communication Error (TX communication error is detected)
• 034-714: Communication Error (TX communication error is detected)
• 034-715: Communication Error (TX communication error is detected)
• 034-716: Communication Error (Image processing too late)
• 034-717: Communication Error (TX communication error is detected)
• 034-718: Communication Error (TX communication error is detected)
• 034-719: Communication Error (TX communication error is detected)
• 034-720: Communication Error (TX communication error is detected)
• 034-721: Communication Error (TX communication error is detected)
• 034-722: Communication Error (TX communication error is detected)
• 034-723: Communication Error (TX communication error is detected)
• 034-724: Communication Error (TX communication error is detected)
• 034-725: Communication Error (TX communication error is detected)
• 034-726: Communication Error (TX communication error is detected)
• 034-727: Communication Error (TX communication error is detected)
Initial Actions
• Lower transmit speed.
• Cycle printer power.
• If the problem persists, use the following procedure.
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ IP Board, PL7.3.3
■ MCU Board, PL7.1.3
■ Fax Board, PL7.3.4
■ “Map 3 - IP Board” on page 7-8
■ “IP Board” on page 7-27
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 Reseat all connectors on the fax
Board, IP Board and the MCU Board.
Does the error persist?
Go to Step 2. Complete.
2 Replace the Fax Board (page 4-105).
Does the error persist?
Go to Step 3. Complete.
