3-30 Xerox Internal Use Only Phaser 3010/3040/WorkCentre 3045 Service
Image Quality
ADF Lines or Streaks
There are lines or streaks on copies from the ADF.
Initial Actions
• Check the document glass.
• Ensure there are no debris on the document glass.
Troubleshooting Reference Table
Applicable Parts Example Print
■ Scanner Assembly (3045NI)
PL8.1.1
■ Scanner Assembly (3045B) PL8.2.1
Troubleshooting Procedure
Step Actions and Questions Yes No
1 Check the output document.
Are there lines or streaks on the
document?
Replace the
original
document.
Go to Step 2.
2 Is there debris on the document
glass?
Clean the
document glass
using a lint-free
cloth.
Go to Step 3.
3 Does the image quality improve? Complete. Go to Step 4.
4 Are there scratches on the
document glass?
Replace the
Scanner
(page 4-109).
Complete.
