![Xerox Phaser 3010 [137/430] Ftp error](/views2/1228085/page137/bg89.png)
Phaser 3010/3040/WorkCentre 3045 Service Xerox Internal Use Only 2-83
Error Troubleshooting
FTP Error
A FTP link error is detected.
Applicable Error
• 031-574: FTP Name Resolve Error
• 031-575: Scan Server Address Error
• 031-576: FTP Server Not Found
• 031-578: Scan Login Failed
• 031-579: Scan FTP Path Error
• 031-582: Scan File Make Error
Initial Actions
• Cycle printer power.
• If the problem persists, use the following procedure.
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ IP Board, PL7.3.3
■ MCU Board, PL7.1.3
■ “Map 3 - IP Board” on page 7-8
■ “IP Board” on page 7-27
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 Reseat all connectors on the IP
Board and the MCU Board.
Does the error persist?
Go to Step 2. Complete.
2 Replace the IP Board (page 4-45).
Does the error persist?
Go to Step 3. Complete.
3 Replace the MCU Board (page 4-43).
Does the error persist?
Contact your
designated
field support for
assistance.
Complete.
