2-94 Xerox Internal Use Only Phaser 3010/3040/WorkCentre 3045 Service
Error Troubleshooting
Carriage Motor Error
An error was detected in the Scanner carriage motor.
Applicable Error
• 062-321: Carriage Motor Error
Initial Actions
• Cycle printer power.
• If the problem persists, use the following procedure.
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ Scanner Assy, PL8.2.1
■ MCU Board, PL7.1.3
■ “Map 3 - IP Board” on page 7-8
■ “Scanner” on page 7-28
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 Reseat the Scanner connectors on
the IP Board and cycle system
power.
Does the error persist?
Replace the
Scanner
(page 4-109).
Complete.
