Xerox Phaser 3010 [134/430] Smb write error
![Xerox Phaser 3010 [134/430] Smb write error](/views2/1228085/page134/bg86.png)
2-80 Xerox Internal Use Only Phaser 3010/3040/WorkCentre 3045 Service
Error Troubleshooting
SMB Write Error
A SMB error is detected.
Applicable Error
• 031-536: SMB Delete Folder Error
• 031-537: SMB Disk Full Error
• 031-556: SMB Write Error
• 031-557: SMB File Duplication Error
• 031-558: SMB Connect Error
Initial Actions
• Cycle printer power.
• If the problem persists, use the following procedure.
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ IP Board, PL7.2.8 (3010/3040)
■ IP Board, PL7.3.3 (3045)
■ MCU Board, PL7.1.3
■ “Map 3 - IP Board” on page 7-8
■ “IP Board” on page 7-27
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 Reseat all connectors on the IP
Board and the MCU Board.
Does the error persist?
Go to Step 2. Complete.
2 Replace the IP Board (page 4-45).
Does the error persist?
Go to Step 3. Complete.
3 Replace the MCU Board (page 4-43).
Does the error persist?
Contact your
designated
field support for
assistance.
Complete.
