Phaser 3010/3040/WorkCentre 3045 Service Xerox Internal Use Only 2-15
Error Troubleshooting
WorkCentre 3045 Error Codes
The WorkCentre 3045 Error Message Summary table lists possible errors, along
with the corresponding code, and page reference for the corrective procedure.
• The Code column lists the code associated with the error.
• The Error Message LCD column shows the message as it appears on the LCD
when the error occurs during normal operation.
• The Error Description column describes the error.
• The Go to column links to the troubleshooting procedure related to the error.
Use this table to identify the proper procedure to correct the reported error.
WorkCentre 3045 Error Message Summary
Code Error Message LCD Error Description Go to
005-121 Paper Jam
005-121
Open ADF Cover and
Clear Jam
ADF Jam 2-54
005-301 Cover Open
005-301
Remove paper then
Close ADF Cover
ADF Cover Open 2-55
010-397 010-397
Code:xxxxxxxx
Restart Printer
Fuser Error 2-56
016-315 016-315 System
Restart Printer
IP ROM Check (Main) Fail 2-57
016-317 016-317
Restart Printer
Contact Support
IfMessageReturns
IP ROM Check (Main) Fail 2-57
016-372 016-372 System
Restart Printer
Contact Support
If Message Returns
Fax Memory Allocation Error 2-58
016-501 Write Flash Error
016-501 System
Contact Support
If Message Returns
Write Flash Error 2-59
016-502 Write Flash Error
016-502 System
Contact Support
If Message Returns
Verify Flash Error 2-59
016-503
016-504
016-506
016-507
SMTP Error
016-50X Scan
Job Failure
E-mail Error 2-60
