2-16 Xerox Internal Use Only Phaser 3010/3040/WorkCentre 3045 Service
Error Troubleshooting
016-718 Memory Full
016-718 Printer
Job too Large
Out of Memory 2-61
016-719 Decode Error
016-719 Printer
Job Failure
Decode Error 2-62
016-720 PDL Request
016-720 Printer
Data Violation
PDL Error 2-64
016-744 Format Error
016-744 System
Invalid Data
Checksum Error 2-63
016-745 Format Error
016-745 System
Invalid Data
Header Error 2-63
016-749 PJL Request
016-749 Printer
Data Violation
PJL Request Error 2-64
016-764 Connect Fail
016-764 Scan
Job Failure
Can not connect to mail server
for sending mail out.
2-65
016-766 SMTP Error
016-766 Scan
Job Failure
Can not transferring completely. 2-65
016-767 Address Error
016-767 Scan
Job Failure
Recipient address is invalid. 2-65
016-791 USB Memory was removed.
016-791 System
Job Failure
USB Memory Removal Error 2-66
016-795 File Format Error
016-795 Printer
Job Failure
File Format Error 2-66
016-797 File Read Error
016-797 Printer
Job Failure
File Read Error 2-66
016-920 Wireless Error
016-920 System
Setup Fail
Wireless Setting Error Timeout
Error
2-67
016-930
016-931
USB Host Error
016-930 System
Unsupported Device
Remove from USB Port
USB Host Error 2-68
016-981 Collate Full
016-981 Printer
Job too Large
Collate Full 2-69
016-985 Mail Size Limits
016-985 Scan
Job Failure
Mail Size Limits Error 2-70
WorkCentre 3045 Error Message Summary
Code Error Message LCD Error Description Go to
