Phaser 3010/3040/WorkCentre 3045 Service Xerox Internal Use Only 2-17
Error Troubleshooting
017-970 Memory Full
017-970 Scan
Job Failure
Out of Memory 2-70
017-980 Report error
017-980 System
Job Failure
Fax Report job fails to report file. 2-71
017-981 Report error
017-981 System
Job Failure
Report File Error 2-71
017-988 PCScan Time Out
017-988 Scan
Job Failure
PCScan Time Out 2-70
018-338 018-338 System
Restart Printer
Contact Support
If Message Returns
Wireless Error 2-67
024-340 024-340
Code:xxxxxxxx
Restart Printer
MCU Firmware Error 2-72
024-360 024-360 System
Restart Printer
Contact Support
If Message Returns
Download Error 2-73
024-371 024-371 System
Restart Printer
Contact Support
If Message Return
MCU Comm. Error 2-74
024-958 Paper Size Mismatch
024-958 Printer
Load Paper then Press P
AAAAA (or BBBBB)
Paper Size Mismatch 2-75
024-963 No Suitable Paper
024-963 Printer
Load Paper
No Suitable Paper 2-76
026-720 USB Memory Full
026-720 Scan
Job Failure
USB Memory Full 2-77
026-721 File Write Error
026-721 Scan
Job Failure
USB Memory Write Error 2-77
026-722 Write Protect
026-722 Scan
Job Failure
USB Memory Write Protect Error 2-77
026-723 File Path Limit
026-723 Scan
Job Failure
File Path Limit Error 2-77
026-750
026-751
026-752
Communication Fail
026-75X Scan
Job Failure
Scan Communication Fail 2-78
WorkCentre 3045 Error Message Summary
Code Error Message LCD Error Description Go to
