Xerox Phaser 3010 [150/430] Misfeed jam
![Xerox Phaser 3010 [150/430] Misfeed jam](/views2/1228085/page150/bg96.png)
2-96 Xerox Internal Use Only Phaser 3010/3040/WorkCentre 3045 Service
Error Troubleshooting
Misfeed Jam
Paper jam was detected at the Main or Bypass Tray.
Applicable Error
• 075-100: Misfeed Jam
Initial Actions
• Check the media path for obstructions or debris.
• Check condition of the Feed Roller and Separator Pad.
• Cycle printer power.
• If the problem persists, use the following procedure.
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ Feed Solenoid, PL2.3.21
■ Registration Sensor, PL2.3.10
■ Main Drive Motor, PL6.1.1
■ MCU Board, PL7.1.3
■ “Map 2” on page 7-4
■ “Drive” on page 7-14
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 Test t h e Registration Sensor.
Does the Registration Sensor
function correctly?
Go to Step 2. Replace the
Registration
Sensor
(page 4-30).
2 Test the Main Drive Motor.
Does the motor function correctly?
Go to Step 3. Replace the
Main Drive
Motor
(page 4-41)..
3 Test the Feed Solenoid.
Does the Feed Solenoid function
correctly?
Go to Step 4. Replace the
Feed Solenoid
(page 4-32).
4 Replace the MCU Board (page 4-43).
Does the error persist?
Contact your
designated
field support for
assistance.
Complete.
