2-14 Xerox Internal Use Only Phaser 3010/3040/WorkCentre 3045 Service
Error Troubleshooting
116 355 116-355
Restart Printer
Contact Support
If Message Return
ESS Network Fatal
Error.
Error during the on-
board network check.
2-113
117 331 117-331
Restart Printer
Contact Support
If Message Return
ESS-related error 2-114
117 332 117-332
Restart Printer
Contact Support
If Message Return
ESS-related error 2-114
117 333 117-333
Restart Printer
Contact Support
If Message Return
ESS-related error 2-114
117 334 117-334
Restart Printer
Contact Support
If Message Return
ESS-related error 2-114
117 349 117-349
Restart Printer
Contact Support
If Message Return
ESS-related error 2-114
117 350 117-350
Restart Printer
Contact Support
If Message Return
ESS-related error 2-114
117 351 117-351
Restart Printer
Contact Support
If Message Return
ESS-related error 2-114
117 366 117-366
Restart Printer
Contact Support
If Message Return
ESS-related error 2-114
124 333 124-333
Restart Printer
Contact Support
If Message Return
ASIC Failure
ASIC failure detected.
2-115
191 310 191-310
Restart Printer
Contact Support
If Message Return
XERO Life Over
The Printer has
reached the
replacement time.
2-117
Phaser 3010/3040 Error Message Summary
Code Error Message Error Description Go to page
