2-30 Xerox Internal Use Only Phaser 3010/3040/WorkCentre 3045 Service
Error Troubleshooting
Regi FB Lead -2.0 mm ~ 2.0 mm,
in 0.1 mm Step
Adjusts Registration of the flatbed
leading edge.
Regi FB Side -1.0 mm ~ 1.0 mm,
in 0.1 mm Steps
Adjusting Registration of the flatbed
side edge.
Auto Registration Reports the result of auto registration
which is performed while the printer
powers up.
IIT I/O Check
■ FB Home Sensor
■ ADF Scan Sensor
■ ADF Document
Sensor
■ ADF Cover Sensor
Tests the scanner sensors.
Scan Counter
Clear
This function clears the flat bed and
ADF counters.
Parameter Value Options
Pulse Dialing Enable Pulse Dialing
NOTE You can not select
Pulse dialing at the Fax
Setting Menu, only
To ne d i al .
0:Disable
1:Enable
Pulse dial make/break
ratio
0: 30% / 70%, 1: 32% / 68%,
2: 33% / 67%, 3: 36% / 64%,
4: 38% / 62%, 5: 39% / 61%,
6: 40% / 60%, 7: 42%/ 58%
Enable 20 PPS DP
NOTE You can not select
Pulse 20PPS dialing at
the Fax Setting Menu.
0:Disable, 1:Enable
DTMF Tone DTMF high tone
level (-dB)
0: -3 dB, 1: -4 dB, 2: -5 dB, 3: -6 dB,
4: -7 dB, 5: -8 dB, 6: -9 dB, 7: -10 dB
DTMF high/low level
difference (dB)
0: 0 dB, 1: -1 dB, 2: -2 dB, 3: -3 dB,
4:- 4 dB, 5: -5 dB
DTMF Dialing
Speed (ms)
0: 70 ms, 1: 80 ms, 2: 85 ms,
3: 90 ms, 4: 95 ms, 5: 100 ms,
6: 105 ms, 7: 110 ms
Tes t Control Panel Description
