2-32 Xerox Internal Use Only Phaser 3010/3040/WorkCentre 3045 Service
Error Troubleshooting
Call Progress
Tone
Freq. Filter
Call Progress Tone Freq.
Filter
0: 340Hz ~ 560Hz
1: 310Hz ~ 485Hz
2: 363Hz ~ 502Hz
3: 276Hz ~ 504Hz
4: 415Hz ~ 460Hz
5: 310Hz ~ 640Hz
6: 370Hz ~ 525Hz
RX Power Rx Call Detection Level 0: -36dB, 1: -37dB, 2: -38dB, 3: -39dB,
4: -40dB, 5: -41dB, 6: -42dB, 7: -43dB,
8: -44dB, 9: -45dB, 10: -46dB,
11: -47dB, 12: -48 dB
TX Power Tx Cable Equalizer 0: 0dB, 1: 2dB, 2: 4dB, 3: 6dB, 4: 8dB,
5: 10dB, 6: 11dB, 7: 12dB
Tx Signal Level 0: -3 dB, 1: -4 dB, 2: -5 dB, 3: -6 dB,
4: -7 dB, 5: -8 dB, 6: -9 dB, 7: -10 dB,
8: -11 dB, 9: -12 dB, 10: -13dB,
11: -14 dB, 12: -15 dB, 13: -16 dB,
14: -17 dB, 15: -18 dB
External Hook
Threshold
High voltage High (20~40 V)
Medium voltage Medium (10~19 V)
Low voltage Low (5~9 V)
FAX Capability
Setting
Best Coding Capability 0: MH, 1: MR, 2: MMR, 3: JBIG
Backup Data
All Clear Clears all of the backup data.
User & System
Clear
Clears stored document data, address
information, communication
management data, the history.
Initializes the system data.
System Data Init Initializes the system data.
Complete Exits diagnostics and returns to
normal operation.
Tes t Control Panel Description
