Besides guaranteeing the necessary air change, the RCU heat recuperative heaters can also recover heat
a high percentage of energy that is contained in foul air.
The heat gained from recycled air is transferred by means of an exchanger to outer, colder air that gets
pre-heated, thereby reducing the thermal shock as compared with inside temperature. During summertime
- when the outer air is characterized by high temperature and humidity - these recuperative heaters similarly
allow to pre-chill outside air if combined with an air-conditioning plant.
RCU
RECUPERATIVE UNIT
WITH EXCHANGER
HEAT RECOVERY UNITS
POSSIBLE INSTALLATION OPTIONS
=
Expulsion air
=
Air inlet
Type 1 Type 2
Type 3 Type 4
SERIES
CERTIFIED IN ACCORDANCE WITH
:
LOW TENSION DIRECTIVE 73/23/CEE
MACHINE DIRECTIVE 89/392/CEE
ELECTROMAGNETIC COMPATIBILITY
DIRECTIVE 89/336/CEE
eventual battery
filters
