PECULIARITY
- AISI 430 stainless steel combustion chamber.
- AISI 430 stainless steel heat exchanger featuring exclusive modular exchange elements.
- Special conveyors on the air inlet section.
- Built-in two-stage atmospheric burner.
- Equipped with command, control and safety electric board.
- Suitable to be installed both in low-pressure or high-pressure circuits.
- Suitable to be installed both inside and outside (SR-UTK version).
SR-UT
HigH efficiency AIR HEATING SECTIONS WITH
INCORPORATED TWO-STAGE ATMOSPHERIC BURNER
EFFICIENCY ~91%
SERIES
