Models
Unit
NTPM 09 NTPM 15 NTPM 17 NTPM 21 NTPM 24 NTPM 36 NTPM 43
Nominal air flow Nm
3
/h 930 1.500 1.600 2.050 2.400 3.600 4.200
USEFUL static pressure Pa 90 100 85 115 105 120 115
Max. absorbed electrical power A 1 1,9 1,9 2,6 2,6 3,9 5,5
Fan speeds n° 3 3 3 3 3 3 3
Electrical supply
V - 50Hz
230 ~ 230 ~ 230 ~ 230 ~ 230 ~ 230 ~ 230 ~
Isolation class B
Battery ranks n° 3 3 4 3 3 3 4
Cooling
Cooling capacity
(1)
W 4.600 7.450 9.070 10.500 13.100 15.700 20.700
Water pressure drop kPa 16 19 21 17 21 22 26
Water flow m
3
/h 0,72 1,2 1,55 1,6 1,9 2,6 3,6
Heating
Heating capacity
(2)
W 9.800 15.500 1.9700 21.600 25.900 35.500 46.300
Water pressure drop kPa 13 19 21 18 22 22 25
Water flow m
3
/h 0,88 1,4 1,76 1,9 2,3 3,2 4,2
(1) Cooling: incoming air temperature 27°C ( dry bulb ), relative humidity 50% - Incoming/outgoing Water temperature 7/12°C – Data referred to the nominal air flow
(2) Heating: incoming air temperature 20°C ( dry bulb ), relative humidity 50% - Incoming/outgoing Water temperature 70/60°C – Data referred to the nominal air flow
TECHNICAL SPECIFICATIONS SERIES
NTPM
