Fan coil units either vertical or horizontal model. Floor, wall or ceiling mounted models and galvanised pre-
painted casing with anti-condensation isolating material, air outlet grid and heat transfer coil made of copper
tube with aluminium fins, that can be connected either on the right or on the left side. Five speed low sound
pressure level centrifugal fan, condensate water basing, cleanable air filter, control system.
KUBO
A BIG
RESISTANT HEART
FAN COIL UNITS
SERIES
CONSTRUCTION CHARACTERISTICS
1. Vent coil (4)
2. Coil connections
3. Fixings holes
4. Condensate collection tray
5. Condensate discharge
6. Fans motor
7. Filters
8. Fans
9. 3 ranks coil
10. Electrical connections
11. Thermostat (optional)
12. 5 speed changeover switch
1
10
9
2
3
5
4
8
7
11
12
6
CERTIFIED IN ACCORDANCE WITH
:
LOW TENSION DIRECTIVE 73/23/CEE
MACHINE DIRECTIVE 89/392/CEE
ELECTROMAGNETIC COMPATIBILITY
DIRECTIVE 89/336/CEE
