The WIMBLEDON patented equipment, a TOTAL CONDENSATION SINGLE-PACKGE AIR TREATMENT

UNIT, provides for continuous and consistent automatic modulation of the heating capacity output as well

as for the possibility to vary static pressure by regulating the outside air damper. This way, not only the

equipment can provide “just in time” heating of premises but it also helps keeping the right pressure inside

pressostatic structures and/or tensostructures – this is why it is particularly indicated with elements cover-

ing tennis courts.

The unit consists mainly of an isolated cabinet receiving the air flow generated by the ventilator group and

where a top-efficiency newly designed heat exchanger is installed. The heat exchanger transfers heat energy

through direct exchange between flue gas and the air flow to be heated. Namely, the air flow passes onto the

special heat exchanger’s hot surface and is thereby warmed up to be later supplied to the environment. The

centrifugal fan’s characteristics make this equipment suitable to be installed wherever very high static pres-

sure is required. Besides; the unit can perform just room ventilation during summertime. The direct exchange

technology employed by this equipment requires lower installation costs but first and foremost allows a tan-

gible reduction of operating cost. As a matter of fact, the most important feature of this system is that heat is

directly transferred to the premises to be heated, thereby avoiding inefficient transformation stages. The result

is a much higher overall performance of the whole system.

This equipment’s UNIQUE PECULIARITY depends on the fact that it has been specifically

designed and proportioned to ALWAYS work at flue gas condensation conditions covering all of

its heating capacity range (maximum and minimum values). This way, the product’s outstanding

thermal efficiency at maximum work output (reaching about 105%) combines with a very high

average seasonal efficiency, thereby allowing a tangible energy saving, a significant reduction of

management costs as well as a concrete decrease of noxious emissions.

The innovative, patented airflow pathway inside the equipment alongside with a heat exchanger struc-

ture employing counter-current and crossed jets have contributed to making the WIMBLEDON series play

a unique, winning role in the framework of such specific applications. Moreover, the valuable stainless steel

materials employed guarantee a safe, long-lasting functioning also at flue gas total condensation conditions.

This appliance has been specifically designed to draw in and transfer treated air downwards and on the same

side, thereby easing the connection of air duct outlets and inlets.

The equipment features a gravity-closing safety damper placed on the outside air inlet in order to avoid the

structure’s quick deflating in case of sudden blocks, as well as a regulation damper on the recirculation air

inlet. All these elements combined can guarantee consistent, even pressure within the structure.

In addition, the WIMBLEDON unit is equipped with two safety fire dampers that are placed on the air inlet

and outlet points respectively. The product’s peculiar characteristics are covered by international patent and

its safety is certified by renowned and professional International Authorities.

TOTAL CONDENSING SINGLE-PACKAGE AIR TREATMENT UNIT

SPECIFICALLY DESIGNED FOR PRESSOSTATIC STRUCTURES
