PECULIARITY
- Autonomous single-package equipment with automatic control of all functions by means
of a cutting-edge microporcessor.
- Filtering, heating, cooling, free-cooling, free-heating, air discharge, air renewal with a
dedicated ventilation unit (CFM unit).
- No intermediate fluids.
- Direct expansion refrigeration up to +40°C .
- Heating by heat pump up to +5°C; heating by high-efficiency INOX stainless steel gas
heat exchanger down to -20°C.
- Operating temperatures between -20° and +40°C.
- Standard version 250 PA, “S version” with high static pressure 450 PA.
SERIE
CF-GAS/P
600-700
AUTONOMUS SINGLE-PACKAGE AIR TREATMENT UNIT
featuring top gLoBaL efficiency systems
EFFICIENCY ~91%
SERIES
