PECULIARITY
- Autonomous single-package equipment with automatic control of all functions by means of
a cutting-edge microporcessor.
- Filtering, heating, cooling, free-cooling, free-heating, air discharge, air renewal.
- No intermediate fluids.
- Direct expansion refrigeration up to +40°C .
- Heating by heat pump up to +5°C; heating by high-efficiency INOX stainless steel gas heat
exchanger down to -20°C.
- Operating temperatures between -20° and +40°C.
- Standard version 250 PA, “S version” with high static pressure 450 PA.
CF-GAS
800-1200
SERIES
condensing AUTONOMUS SINGLE-PACKAGE AIR TREATMENT
UNIT FEATURING
HIGH PERFORMANCES
EFFICIENCY ~104%
