Thermal Performance GASTEC certified
Cooling performance following EUROVENT conditions
64
CF
-
GAS
AUTONOMOUS SINGLE
PACKAGE AIR TREATMENT UNIT
SERIES
ROOF TOP
Air treatment unit made as follows:
The cooling section uses scroll compressors running with R407 ecologic gas (L1 Class) and located in a
specific van with independent cooling circuits.
All are controlled by microprocessor logic. There are exchangers with big, frontal surface with sub-cooling
circuits, independent working axial fans.
The heating section is made by atmospheric multigas burners, combined with patented, big surface, high
efficiency and stainless steel AISI 430 heat exchangers. It assures always more than 90% efficiency even
by outside temperature, less than 0°C.
The treatment section is made by an external air mixing chamber / air recycling with undulated filter cells,
evaporation coils, an output fan group with double centrifugal fans and double aspiration and low sound
pressure connected to variable belt transmission with pulley, with electric sledding engine; all of which is
simplified by easy inspection doors. All models are available in low-temperature version.
APPLICATIONS
EFFICIENCY ∼ 91%
CERTIFIED IN ACCORDANCE WITH:
DIRECTIVE PED 97/23/CEE
GAS DIRECTIVE 90/396/CEE
LOW TENSION DIRECTIVE 73/23/CEE
MACHINE DIRECTIVE 89/392/CEE
ELECTROMAGNETIC COMPATIBILITY
DIRECTIVE 89/336/CEE
