PECULIARITY
- Employing R410A eco-friendly refrigerating gas.
- Energy efficiency ratio - E.E.R up to 4,1.
- Modulating control of axial fans speed.
- Auxiliary hydraulic connections.
- Water-flow switch to check appropriate water-flow rate.
- Advanced electronics.
- Machine equipped with built-in hydric group, circulator, expansion tank, water-flow switch,
pressure gauge, air vent.
- Possibility to add a supplementary storage tank.
E.E.R. ~ 4,1
FRESH
SERIES
HigH performance WATER CHILLERS
WITH R410A ECO-FRIENDLY REFRIGERATING GAS
