70
71
Treatment unit for air heating only, employing high-efficiency gas and designed to be installed both inside and out-
side; the external cabinet features an IP44 protection degree and accommodates all the electrical elements inside.
Additional features are: top protective cover made of galvanized steel sheet, air intake grid with rain-proof fins, galva-
nized steel shelf angles, forced exhaust, electronic ignition, flame control by ionization, patented heat exchanger with
combustion chamber and modulating exchange elements entirely made of AISI 430 stainless steel centrifugal fans
driven by a variable gear transmission belt, command and control equipment for total safety. Available versions:
SINGLE-PHASE with fixed thermal power: UTK/UT standard version, UTK-S/UT-S version for high static pressure.
TWO-PHASE with two-stage thermal power: UTK-/UT-2 standard version, UTK-2S/UT-2S version for high static
pressure.
The UTK series also comes in a “low temperatures” version.
UTK-UT
GAS FIRED
AIR HANDLING UNITS
WARM AIR HEATERS
UT SERIES FOR INDOOR INSTALLATION
The Air Handling Unit series UT represent the
version for indoor installation, but with the same
features of the outdoor version UTK. The high air-flow
performances together with its employing versatility,
makes possible to install the UT unit either inside the
room to heat up, than in separate external rooms,
or in expressly built thermal power stations. Further
accessories for a suitable installation can be chosen
within the huge proposed range for outdoor version.
SERIES
EFFICIENCY ∼ 91%
CERTIFIED IN ACCORDANCE WITH:
GAS DIRECTIVE 90/396/CEE
LOW TENSION DIRECTIVE 73/23/CEE
MACHINE DIRECTIVE 89/392/CEE
ELECTROMAGNETIC COMPATIBILITY
DIRECTIVE 89/336/CEE
