Thermal Performance GASTEC certified
TECHNICAL SPECIFICATIONS SERIES
WIMBLEDON
AERAULIC SECTION
Models Unit WIMBLEDON 145 WIMBLEDON 245 WIMBLEDON 395
Nominal air flow Nm
3
/h 14.000 23.000 37.000
USEFUL static pressure std motor Pa 250 250 250
USEFUL static pressure bigger motor Pa 500 500 500
HEATING SECTION
gas HEaT EXCHaNgER - MaX OUTPUT fUNCTiONiNg aT CONdENsaTiON
Models U. M. WIMBLEDON 145 WIMBLEDON 245 WIMBLEDON 395
Minimal efficiency % 98,7 99,0 99,1
Max. USEFUL heating capacity
kW 147,6 246,1 393,7
kcal/h 126.936 211.646 338.582
Max. temperature deviation °K 31,0 31,5 31,5
gas HEaT EXCHaNgER - MiN OUTPUT fUNCTiONiNg aT CONdENsaTiON
Models U. M. WIMBLEDON 145 WIMBLEDON 245 WIMBLEDON 395
Max efficiency % 105,0 105,2 105,5
Min. USEFUL heating capacity
kW 73,8 123,05 196,85
kcal/h 63.468 105.823 169.291
Min. temperature deviation °K 15,5 15,7 15,7
ELECTRICAL SPECIFICATIONS
Models U. M. WIMBLEDON 145 WIMBLEDON 245 WIMBLEDON 395
Electrical supply
V - 50Hz
400 3N ∼ 400 3N ∼ 400 3N ∼
