86
87
Totally sealed for outdoor installation wall boiler, composed of: galvanized pre-coated cabinet, water heat
exchanger and atmospheric burner with electronic burner ignition and flame control by ionisation.
Gas valve, centrifugal exhaust extractor, circulator with automatic air pump device and automatic circulator
anti-bloc device. Expansion tank, water temperature probe, automatic anti-frost device, pressure switch by lack
of water and electronic control and safety system.
Suspended water air heaters with thick galvanised painted steel casing, self-supporting galvanised steel
structure and copper tubes with aluminium fins exchange coil.
Steel water connections both with blow-off valves and both fixed on anti-break clamp bracket and special low
sound propeller fan with two or three speed electrical motor.
TANDEM
AUTONOMOUS
COMBINED SYSTEM
BOILER - AIR HEATER
APPLICATIONS
Tandem is the solution for the heating of spaces
in which the security regulations forbid the
indoor installation of gas-fired units, therefore it
is particularly indicated for:
•Carpentries
•Car-repairgarages
•Spacesinwhichpaintingsaredonewith
inflammable thinners.
•Textileindustries
•Paperindustries
•Printingworks
•Publicandcommercialareas,etc.
CERTIFIED IN ACCORDANCE WITH
:
GAS DIRECTIVE 90/396/CEE
LOW TENSION DIRECTIVE 73/23/CEE
MACHINE DIRECTIVE 89/392/CEE
ELECTROMAGNETIC COMPATIBILITY
DIRECTIVE 89/336/CEE
SERIES
RENDIMENTO ∼ 90%
