Models Unit
RCU 33 HE RCU 55 HE RCU 110 HE RCU 175 HE RCU 220 HE RCU 255 HE RCU 320 HE RCU 410 HE
Nominal air flow rate
(1)
Nm
3
/h 310 650 1.050 1.800 2.220 2.600 3.250 4.290
USEFUL static pressure
(1)
Pa 50 65 80 130 100 110 125 130
Motor power W 92 x 2 90 x 2 147 x 2 350 x 2 350 x 2 350 x 2 550 x 2 750 x 2
Fan speed N° 1 1 3 3 3 3 3 2
Electrical supply V - 50Hz 230 ~ 230 ~ 230 ~ 230 ~ 230 ~ 230 ~ 230 ~ 400 3N ~
(1) Values referred to nominal air flow rate, behind recover unit and filters
HEAT RECOVERY UNiT
Models Unit
RCU 33 HE RCU 55 HE RCU 110 HE RCU 175 HE RCU 220 HE RCU 255 HE RCU 320 HE RCU 410 HE
Winter function
(2)
Efficiency (temp./entalpy) % 85/82 72/69 71/68 72/69 72/69 73/69 69/67 63/63
Recovered heat output kW 3,5 6,3 10,0 17,4 21,3 25,2 30,5 38,0
Treated air temperature °C 16,1 13,0 12,7 13,0 12,9 13,1 12,3 10,6
Treated air humidity % 53,0 57,6 58,7 57,6 57,9 57,2 60,3 67,5
Summer function
(3)
Efficiency (temp./entalpy) % 92/73 80/69 79/69 80/69 79/69 80/69 77/68 70/66
Recovered heat output kW 1,3 2,5 4,0 6,9 8,5 10,0 12,3 15,7
Treated air temperature °C 26,5 27,2 27,3 27,2 27,3 27,2 27,4 27,8
Treated air humidity % 56,0 53,7 53,4 53,7 53,4 53,7 53,1 51,9
(2) Winter nominal conditions: outside air –5°C (dry bulb), relative humidity 80%, room air 20°C (dry bulb), relative humidity 50%.
(3) Summer nominal conditions: outside air 32°C (dry bulb), relative humidity 50%, room air 26°C (dry bulb), relative humidity 50%.
FiLTERS
Models Unit
RCU 33 HE RCU 55 HE RCU 110 HE RCU 175 HE RCU 220 HE RCU 255 HE RCU 320 HE RCU 410 HE
Efficiency G3 G3 G3 G3 G3 G3 G3 G3
Frontal air speed m/s 1,0 1,9 2,0 2,5 2,8 1,8 2,6 3,0
A
B
C
Models
Dimensions mm
Weight
Kg
A B C
RCU 33 HE
750 1.075 425 67
RCU 55 HE
750 1.075 425 71
RCU 110 HE
860 1.205 460 102
RCU 175 HE
860 1.400 530 139
RCU 220 HE
960 1.540 560 152
RCU 255 HE
1.230 1.720 600 178
RCU 320 HE
1.230 1.720 600 194
RCU 410 HE
1.230 1.720 600 207
OVERALL DIMENSIONS
TECHNICAL SPECIFICATIONS SERIES
RCU-HE
