Suspended water air heaters made of the following: thick galvanised painted steel casing, self-supporting
galvanised steel structure, cooper tubes with aluminium fins exchange coil, steel water connections both
with blow-off valves and both fixed on anti-break clamp bracket and special low sound propeller fan a two
or three speed electrical motor.
AZN
NEW ACOUSTIC
COMFORT
WATER AIR HEATER
AZN SERIES IS ALSO AVAILABLE IN FOLLOWING VERSIONS:
AZN-X: with case in stainless steel AISI 430;
AZN-F: for heating and cooling, with condensate basin;
AZN-V: with steam battery.
CONSTRUCTION CHARACTERISTICS
4
2
1
3
5
1. Electric propeller fan with safety protection
grid.
2. Fan panel.
3. Collector with upper and bottom air vent and
anti-torsion plate.
4. Exchange battery copper-aluminium.
5. Demountable frontal panel with horizon-
tal diffusion fins. Galvanized painted steel
casing.
SERIES
CERTIFIED IN ACCORDANCE WITH
:
LOW TENSION DIRECTIVE 73/23/CEE
MACHINE DIRECTIVE 89/392/CEE
ELECTROMAGNETIC COMPATIBILITY
DIRECTIVE 89/336/CEE
