Tecnoclima VX 930 [36/116] Condensing warm air heaters with modulating burner

Description Unit A B C D E F G H L N P

∅ chimney

Weight Kg

ENERGY 60 mm 812 540 1.580 400 625 490 600 1.305 27 – – 150 130

ENERGY 105 mm 1.060 760 1.926 500 900 700 900 1.667 30 – – 200 255

ENERGY 160 mm 1.300 900 2.120 781 1.182 840 1.240 1.905 30 – – 250 445

ENERGY 220 mm 1.500 1.000 2.120 781 1.382 940 1.440 1.905 30 – – 250 535

ENERGY 320 mm 1.700 1.200 2.350 781 1.582 1.140 1.640 2.160 30 – – 300 740

ENERGY 460 mm 2.090 270 2.870 882 1.972 1.210 2.030 2.585 30 1.000 1.870 330 1.175

ENERGY 640 mm 2.500 1.500 3.120 882 2.382 1.440 2.440 2.815 30 1.000 2.120 370 1.637

ENERGY 970 mm 3.500 1.500 3.320 860 3.360 1.440 3.440 3.030 30 1.200 2.120 380 2.175

ENERGY 60 ÷ 105

ENERGY 160÷970

The CONDENSING WARM AIR HEATER ENERGY provides controlled heating of the air to be sup-

plied to residential, commercial and industrial premises. The equipment consist mainly of an isolated cabinet

receiving the air flow produced by the ventilator group. The cabinet contains a high-efficiency INOX stainless

steel heat exchanger which transfers the thermal power by means of direct exchange between combustion

products and the air flow to be treated. Such air is heated when passing onto the exchanger’s hot surface

and it is then distributed to the premises. The centrifugal fan’s characteristics make the equipment suitable to

be installed where air is to be distributed through pipings or – more generally – where high static pressure

is requied. During summertime, this equipment can also perform room ventilation only. The direct exchange

technology employed by this equipment requires lower installation costs but first and foremost it allows a

tangible reduction of operating costs. The most important feature of this system is that heat is directly trans-

ferred to the premises to be heated, thereby avoiding inefficient transformation stages. The result is a much

higher overall performance of the system.

The ENERGY unit is manufactured with valuable STAINLESS steel materials, thereby guar-

anteeing a safe, long-lasting functioning also at flue gas condensation conditions. This peculiar

feature allows to monitor in a continuous and consistent way the equipment’s heating capacity

output according to the immediate needs of end users. Moreover, operating economy is maxi-

mized thanks to the functioning mode at condensation conditions. This equipment is also suit-

able to fully treat outside air, whose temperature changes from time to time according to the sea-

son. All functions are managed in a fully automatic way by means of a complete and well-tested

electronic controller that is interfaced with temperature sensors.

A wide choice of accessories (such as filters, remote controls, diffusion plenums, regulation dampers,

aspiration grids, kit for high static pressure, etc.) come in to complete the product. Product safety is certified

by renowned and professional International Authorities.

CONDENSING WARM AIR HEATERS

WITH MODULATING BURNER

CHIMNEY

CHIM.
