Thermal Performance GASTEC certified
AERAULIC SECTION
Models Unit DUO-MO 145 DUO-MO 245 DUO-MO 395 DUO-MO 615 DUO-MO 865
Nominal air flow Nm
3
/h 14.000 23.000 37.000 57.500 80.500
USEFUL static pressure std motor Pa 250 250 250 250 250
USEFUL static pressure bigger motor Pa 500 500 500 500 500
HEATING SECTION
gas HEaT EXCHaNgER - MaX OUTPUT fUNCTiONiNg aT CONdENsaTiON
Models Unit DUO-MO 145 DUO-MO 245 DUO-MO 395 DUO-MO 615 DUO-MO 865
Minimal efficiency % 102,9 103,4 103,9 104,4 104,5
Max. USEFUL heating capacity
kW 147,6 246,1 393,7 618,2 866,0
kcal/h 126.936 211.646 338.582 531.652 744.760
Max. temperature deviation °K 31,0 31,5 31,5 32,0 32,0
gas HEaT EXCHaNgER - MiN OUTPUT fUNCTiONiNg aT CONdENsaTiON
Models Unit DUO-MO 145 DUO-MO 245 DUO-MO 395 DUO-MO 615 DUO-MO 865
Max efficiency % 106,8 107,1 107,5 107,9 108,2
Min. USEFUL heating capacity
kW 73,8 123,05 196,85 309,1 433,0
kcal/h 63.468 105.823 169.291 265.826 372.380
Min. temperature deviation °K 15,5 15,7 15,7 16,0 16,0
ELECTRICAL SPECIFICATION
Models Unit DUO-MO 145 DUO-MO 245 DUO-MO 395 DUO-MO 615 DUO-MO 865
Electrical supply V - 50Hz
400 3N ∼ 400 3N ∼ 400 3N ∼ 400 3N ∼ 400 3N ∼
TECHNICAL SPECIFICATIONS SERIES
DUO-MO
