Warm air heaters, with high combustion efficiency, for direct air throw or air ducting, working either with light
oil or gas burner. Very thick combustion chamber and high efficiency patented trapezoidal elements heat
exchanger. Low sound pressure level centrifugal fans and electronic control and safety system. Cabinet heater
robustly constructed, with painted steel panels, fitted with a radiant sheet insulation. Tecnoclima’s 5 models
have been designed for residential environments heating: detached houses or cottages and in various situa-
tions where complete air treatment is needed (such as heating, filtering etc.).
HB
GAS AND OIL SPACE HEATERS
FOR RESIDENTIAL HEATING
WARM AIR HEATERS
CONSTRUCTION CHARACTERISTICS
8
3
5
7
6
1
2
4
5
1. Combustion chamber with flame inversion made of thick steel
(Cor-Ten), resistant to high temperatures and featuring low thermal
load. Perfectly cooled in all of its poins.
2. The top-efficiency heat exchanger has exchange elements with
fume pipes featuring a V, flat tubular section with swil impressions.
3. Wide inspection door for rational and easy pipe cleaning.
4. Gas or oil burner.
5. External cabinet made of finely-painted steel sheet detachable
panels, fitted with radiation-proof heat insulation.
6. Dual intake centrifugal fan with single-phase electric engine that
is directly coupled to the fan wheel.
7. Heating / Stop-Fan Only control switch.
8. Removable and regenerative air filter.
SERIES
CERTIFIED IN ACCORDANCE WITH:
GAS DIRECTIVE 90/396/CEE
LOW TENSION DIRECTIVE 73/23/CEE
MACHINE DIRECTIVE 89/392/CEE
ELECTROMAGNETIC COMPATIBILITY
DIRECTIVE 89/336/CEE
EFFICIENCY ∼ 90%
