Tecnoclima VX 930 [104/116] Special equipment
![Tecnoclima AZN 33 [104/116] Special equipment](/views2/1787161/page104/bg68.png)
102102
103103
Alongside with “traditional” equipment, Tecnoclima designs and manufactures appliances for special uses or
to be employed whenever specific performances are required in the framework of technological processes.
Such appliances fully satisfy the need for overheated air or air with low heat drops.
Versions featuring very high efficiency, flame modulation, condensing functioning mode, variable-
speed fans, as well as suitable for very high static pressure or for low temperatures are available.
Tecnoclima designs special equipment to meet customized requirements:
•108% (combustion efficiency)
•2.500kW (heatingcapacityinput)
•55.000Pa (usefulstaticpressure)
•150.000Nm
3
/h (air flow rate)
•600°C (overheatedairtemperature)
•–55°C (outsideairtemperature)
Plan for an appliance equipped with heat exchanger to produce overheated air for technological processes.
Outside air is drawn at low temperature and is then released at a useful static pressure of 54,000 Pa.
CUSTOMIZED PROJECTS
SPECIAL EQUIPMENT
