Tecnoclima VX 930 [96/116] Series

9494

9595

The VX fan coil features a prepainted, light-coloured steel sheet cabinet (only 220 mm thick) and ABS air outlet

grid with side inspection holes that can be opened to reach the control panel. The support structure is made of

very thick galvanized steel sheet with dedicated holes to be fixed to the wall/ceiling, as well as with internal ther-

moacoustic insulation (M1 standards). The condensation collector is equipped with both discharge device and

thermal insulation (M1 standards). The high-efficiency heat exchange battery (Turbulent Fins with high Reynolds

number) is made of copper piping and aluminium fins that are blocked by mechanical expansion. The battery joints

are equipped with nonspinning device, manual air vent valves and manual water discharge valves. They are nor-

mally placed on the left-hand side of the appliance, yet they can be mounted on the right-hand side upon request

and are easily reversible in any case. The ventilator group consists of 1, 2 or 3 dual-intake centrifugal fans featuring

last-generation plastic fins directly coupled to the engine. The electric engine is equipped with Klixon thermal pro-

tector and a gear condenser working continuously (IP42, B-class standards). The high-efficiency air filter is made

of polyester acrylic fabric and can be regenerated by washing it with water, by blowing or else by suction.

EVOLUTION

OF THE SPECIES

FAN COIL UNITS

AVAILABLE VERSIONS

VX-VA

vertical wall version

VX-HB

horizontal roof version

VX-CH

horizontal build in version

SERIES

CERTIFIED IN ACCORDANCE WITH

LOW TENSION DIRECTIVE 73/23/CEE

MACHINE DIRECTIVE 89/392/CEE

ELECTROMAGNETIC COMPATIBILITY

DIRECTIVE 89/336/CEE
