Tecnoclima VX 930 [24/116] Condensing autonomus single package air treatment unit featuring high performances

Tecnoclima VX 930 [24/116] Condensing autonomus single package air treatment unit featuring high performances

2222

2323

The CF-GAS 800/1200 autonomous single-package CONDENSATION AIR TREATMENT UNITS provide

for complete air treatment.

This equipment combines several technologies to filter, heat, cool and dehumidify the air to be supplied

to commercial and industrial premises. The unit consists mainly of an isolated cabinet receiving the air flow

generated by the ventilator group and where a top-efficiency condensation heat exchanger is installed, there-

by providing for heating effect modulation. In the heating phase, the heat exchanger transfers heat energy

through direct exchange between flue gas and the air flow to be heated. Namely, the air flow passes onto the

heat exchanger’s hot surface and is thereby warmed up to be later supplied to the environment. Also cooling

is performed without any intermediate fluid, through the so-called technique of “mechanical compression and

direct expansion” of the refrigerating gas – something which can be achieved thanks to two separate refriger-

ating circuits working independently. The centrifugal fan’s characteristics make this equipment suitable to be

installed wherever very high static pressure is required. The unit can perform air mixture, renovation, filtering

and discharge, as well as just room ventilation during summertime.

The direct exchange technology employed by this equipment requires lower installation costs but first and

foremost allows a tangible reduction of operating cost. As a matter of fact, the most important feature of this

system is that heat is directly transferred to the premises to be heated, thereby avoiding inefficient transfor-

mation stages. The result is a much higher overall performance of the whole system.

The CF-GAS unit is manufactured with valuable stainless steel materials that allow coupling

with burners working at variable heating power mode (both modulating and/or two-phase).

It guarantees a safe, long-lasting functioning also at flue gas condensation conditions. This

peculiar feature allows to monitor in a continuous and consistent way the equipment’s heating

capacity output. Moreover, operating economy is maximized thanks to the functioning mode at

condensation conditions. The aforementioned characteristics make this equipment also suitable

to fully treat outside air intake for air renovation purposes, whose temperature changes from

time to time according to the season.

The refined watertight cabinet is protuberance-free and its thermal well-insulated panels can be washed

inside. These features perfectly allow to install the equipment outside with no additional protection needed,

even under extreme climatic conditions reaching down to -45°C (provided it is fitted with a specific kit). All

functions are managed in a fully automatic way by means of a complete electronic controller on the equip-

ment’s side that can be interfaced with a user-friendly remote control device or yet even more complex

appliances. A wide choice of accessories (such as regulation dampers, customized power capacity, remote

controls, kit for high static pressure, etc.) come in to complete the product. Product safety is certified by

renowned and professional International Authorities.

CONDENSING AUTONOMUS SINGLE-PACKAGE AIR TREATMENT

UNIT FEATURING HIGH PERFORMANCES
