Tecnoclima VX 930 [25/116] Aeraulic section
![Tecnoclima VX 930 [25/116] Aeraulic section](/views2/1787161/page25/bg19.png)
2222
2323
Thermal Performance GASTEC certified
Cooling performance following EUROVENT conditions
TECHNICAL SPEFICATIONS SERIES
CF
-
GAS
AERAULIC SECTION
Models Unit
CF-GAS 800 CF-GAS 900 CF-GAS 1000 CF-GAS 1100 CF-GAS 1200
Air flow rate Nm³/h 28.000 33.000 39.000 46.000 58.000
USEFUL static pressure std motor Pa 250 250 250 250 250
Electrical power std motor kW 7,5 9,2 11,0 15,0 2 x 9,2
Air flow rate “S” version (with 250 Pa) Nm³/h 33.000 39.000 45.000 54.000 69.000
USEFUL static pressure “S” version Pa 450 450 450 450 450
Electrical power “S” version kW
2 x 5,5 2 x 7,5 2 x 9,2 2 x 11 3 x 9,2
Fresh air flow rate (CF-GAS/X) Nm
3
/h 28.000 33.000 39.000 46.000 58.000
HEATING SECTION
gas HEaT EXCHaNgER - MaX OUTPUT fUNCTiONiNg
Models Unit
CF-GAS 800 CF-GAS 900 CF-GAS 1000 CF-GAS 1100 CF-GAS 1200
Max. USEFUL heating capacity output
kW 230,0 291,0 348,0 415,0 524,0
kcal/h 198.100 250.000 298.500 356.900
450.000
Max. temperature deviation °K 24,5 26,0 26,0 26,5 26,5
gas HEaT EXCHaNgER - MiN OUTPUT fUNCTiONiNg aT CONdENsaTiON
Models Unit
CF-GAS 800 CF-GAS 900 CF-GAS 1000 CF-GAS 1100 CF-GAS 1200
Max. efficiency % 102,8 104,0 102,9 104,1 102,9
Min. USEFUL heating capacity output
kW 76,7 97,0 116,0 138,3 175,0
kcal/h 66.033 83.333 99.760 118.967 150.500
Min. temperature deviation
°K 8,2 8,7 8,5 8,8 8,8
COOLING SECTION
Models Unit
CF-GAS 800 CF-GAS 900 CF-GAS 1000 CF-GAS 1100 CF-GAS 1200
Max cooling capacity output
kW 210,0 240,0 290,0 340,0 440,0
frig/h 180.600 206.400 249.400 292.400 378.400
Sensible cooling capacity output
kW 147,0 168,0 203,0 238,0 308,0
frig/h 126.420 144.480 174.580 204.680 264.880
Min cooling capacity output
kW 105,0 120,0 145,0 170,0 220,0
frig/h 90.300 103.200 124.700 146.200 189.200
Compressors n° 2 2 4 4 4
ELECTRICAL SPECIFICATION
Models Unit
CF-GAS 800 CF-GAS 900 CF-GAS 1000 CF-GAS 1100 CF-GAS 1200
Electrical supply V - 50Hz
400 3N ∼ 400 3N ∼ 400 3N ∼ 400 3N ∼ 400 3N ∼
